Oras Electra, Washbasin faucet, 3 V, Bluetooth, 9212FZ-33

Variants

9212FZ-33 | Washbasin faucet, 3 V, Bluetooth

Oras Electra Safety

Name: Oras Electra Safety 9212FZ-33
Brand: Oras

EAN code
6414150101700

Active markets
FIN, SWE, NOR, DNK, POL, EST, LVA, LTU

Electra 92 series is giving you a whole new modern design with its rounded square body and spout. Giving you new fresh and updated design.
Design compliments the new trends of the modern bathroom with its more squared design.

Key Features
Aerator with Tilt function +/- 10° for more flexible installation
Newest Sensor technology for better detection and operation comfort
Bluetooth technology for easy adjustment to personalize settings
Antiscalding protection
Temperature measurement
Bluetooth Remote bidetta
Battery and power cable

Find local retailer

Datasheet

Oras Electra

More than 30 years of experience in electronic faucets truly shows in Oras Electra, our most widely used and versatile touchless faucet family. Oras introduced the touchless faucets in the public premises already in the 1990s, and in the 21st century, the electronic faucets have rapidly become more common also in the household use. With touchless faucets, water consumption can be reduced by half, while user-friendliness and hygiene rise to a whole new level.

Discover All products

Features

Aerator PCA® - constant flow rate regardless of pressure variations, Adjustable flow angle
Connection Flexible inlet pipes
Electronic parts Advanced PSD sensor, Light indicated function(s), Low battery indicator
Hand shower Remote-operated Smart Bidetta
Lever/Handle Temperature control handle
Mechanical parts Mixing valve for manual temperature control, Non-return valve(s), Litter filter(s)
Number of spray functions 1 spray function
Shower parts Hand shower, Shower holder, Shower hose (1750 mm)
Advanced features 3S-installation system for safe and simple mounting, Software settings adjustable via App
Spout Fixed spout
Color Matt black
Temperature Adjustable hot water stop (included, retrofittable), Smart antiscalding protection

Software settings

Afterflow period 3 s (1-20 s)
Automatic flush off (off/1-120 h)
Automatic flush period 30 s (1-1800 s)
Max. flow period 2 min (1 - 1800 s)

Flow attributes

Flow-rate at 300 kPa 0.08 l/s
Pressure loss with flow (0.1 l/s) 470 kPa (70% qv = 230 kPa)

Technical properties

Backflow prevention (EN1717) EB
Connection size G3/8
Hot water supply max. +70°C
Material Composite
Projection 117 mm
Working pressure 100 - 1000 kPa

Electronics

Battery AA 1.5 V Lithium x 2
Bluetooth version 5.x (D060576)
Electrical Connection 9 V

Regulations

EU Directives Radio Equipment Directive 2014/53/EU , Low Voltage Directive 2014/35/EU , EMC Directive 2014/30/EU , RoHS Directive 2011/65/EU
EN standard EN 15091, ETSI EN 301 489-1 V1.9.2 , ETSI EN 300 328 v2.2.2 , EN 61000-6-1:2007 , EN 61000-6-3:2007+A1:2011+AC:2012 , EN 60335-1:2012+A11+A13+A1+A14+A2+A15:2021, Part 19.11.4
Noise class I (ISO 3822)
Protection class IP 55

Approvals and Declarations

STF EUFI29-24001542-TH
KIWA SE 1904

Sustainability

EPD module A1 (kg CO2 eq.) 5,86
EPD module A1-A3 (kg CO2 eq.) 6,65
EPD module A2 (kg CO2 eq.) 0,28
EPD module A3 (kg CO2 eq.) 0,53
EPD module A4 (kg CO2 eq.) 0,26
EPD module B7 (kg CO2 eq.) 744,00
EPD module C2 (kg CO2 eq.) 0,01
EPD module C3 (kg CO2 eq.) 0,00
EPD module C4 (kg CO2 eq.) 1,58
EPD module D (kg CO2 eq.) -1,25

SP9212FZ-33 Washbasin faucet

Ask pricing from your local retailers.

	Spare parts		Code	Spare part guide
01		Aerator, STD M24x1 HC A (Matt black)	1017197V-33
02		Pilot valve	1008658V	Download
03		Sensor, 3/9 V, Bluetooth	1012464V	Download
04		Temperature regulator	1010630V	Download
05		Temperature control handle (Matt black)	1017587V-33	Download
06		Fixing set	602610V	Download
N.I.		Battery, 1.5 V AA Lithium	600599V
